Chapter 9. Headers

9.1. Microcontroller Headers

Table 9-1 to

show the

Table 9-4

microcontroller pin headers and their corresponding microcontroller connections. The header pins

connect directly to the microcontroller pin unless otherwise stated.

J1

Pin

Circuit Net Name

Device

Pin

Pin

Circuit Net Name

Device

Pin

1 PIN1

1

2 PIN2

2

3 AVCC

3

4 CON_X2

4

5 CON_X1

5

6 NC

6

7 RESn

7

8 NC

8

9 Ground

9

10 CON_OSC2

10

11 CON_OSC1

11

12 UC_VCC

12

13 DLCDD4

13

14 DLCDD5

14

15 IO_4

15

16 IO_5

16

Table 9-1: J1

J2

Pin

Circuit Net Name

Device

Pin

Pin

Circuit Net Name

Device

Pin

1 IO_6

17

2 IO_7

18

3 DLCDD6

19

4 DLCDD7

20

5 LED0

21

6 WKP_ADTRGn

22

7 LED1

23

8 TRISTn

24

9 DLCDE

25

10 PIN26

26

11 PIN27

27

12 TRIGa

28

13 TRIGb

29

14 TMR0

30

15 DLCDRS

31

16 Un

32

Table 9-2: J2
