Rinnai Corporation RHFE-750ETRA 37
Parts List
ITEM QTY PART
NO.
DESCRIPTION
COMMENTS
90
1
10271
PACKING FOR AIR INLET BOX
91
1
10278
PACKING COMB FAN RHFE750ETR
92
1
10796
AIR INLET ASSEMBLY RHFE750 US
93
1
10349
AIR INLET HOSE
94
1
4328
AIR INLET ELBOW B 50x50
95
1
10330
HOSE SS 10 530 3/8SAE RHFE750
96
1
10567
VALVE 3/8" SAEM-FLARE 1/2"NPTF
97
1
10797
PCB ASSEMBLY RHFE750
98
1
10768
FLAME ROD KIT RHFE750
CONTAINS 3 x FLAME RODS
99
1
10770
FLAME ROD BRACKET KIT RHFE750
CONTAINS 3 x BRACKETS
100
1
10792
CONVECTION FAN ASSEMBLY RHFE750 US
101
1
10769
FLAME ROD SLEEVE KIT RHFE750
CONTAINS 3 x SLEEVES
102 1 10798
RECEIVER ASSEMBLY RHFE750
103
1
10765
CONTROL PCB KIT RHFE750
CONTAINS 4 x PCB SPACERS
104
1
10771
BODY PLUG KIT RHFE750
CONTAINS 2 x BODY PLUGS
105
1
10253
PCB DISPLAY RHFE750ETR
106
1
10256
PRESSURE SWITCH RHFE US
107
1
10528
TUBE SILICON BLACK 7x4x1200
108
1
10527
TUBE SILICON CLEAR 6x3x700
109
1
10377
ELECT JUNCTION BOX BODY R750
110
1
7972
ELECTRICAL JUNCTION BOX COVER
111
1
9073
SCREW M4 X 20 PAN PHIL ZINC
112
1
9233
WASHER SPRING M4 ZP
113
2
9186
NUT M4 ZP
114
2
9231
WASHER FLAT M4 ZP
115 1 10378
HARNESS
FUSED POWER USA RHFE
116 1 10281
HARNESS FLAME ROD
117 1 10282
HARNESS
THERMISTOR
118
1
10283
HARNESS OHS THERMAL FUSE
119
1
10284
HARNESS CONTROL PANEL
120 1 10285
HARNESS
RECEIVER
121 1 10286
HT
LEAD
122
1
10289
HARNESS COMB FAN
123
1
10348
HARNESS MAIN RHFE750ETR
124
1
10480
HARNESS COMB FAN SPEED
125 1 10539
HARNESS
PRESSURE SW US
126
1
10507
HARNESS COMB FAN THERMISTOR FLY
127
1
10767
GROMMET KIT RHFE750
CONTAINS 4 x Ø4 AND
2 x 2Ø1.8 HOLED GROMMETS
128
129
1
10776
PLASTIC CLIP KIT RHFE750
130
1
10766
SPARKER KIT RHFE750
INCLUDES PCB SPACERS
131
1
10773
CONTROL PAN COVER KIT RHFE750
INCLUDES BUTTON
132
1
10259
TRANSFORMER US RHFE750ETR
133
1
10563
CABLE CLAMP RHFE750 USA
134
1
10506
HARNESS COMB FAN THERMISTOR
ALSO COMES AS PART OF
COMBUSTION FAN
135
1
10435
TUBE CONDENSATE LOWER
136
1
10438
TUBE SILICON BLACK 7X4X80
137
1
10465
CLIP HOSE 6mm
138 1 10531
CONDENSATE
TRAY
380mm
** Always refer to the data plate for correct information.
