Rinnai Corporation RHFE-750ETRA 35
Parts List
1 1 10201 PANEL BASE RHFE750ETR
2 2 10777 FOOT KIT RHFE
3 1 BRACKET COMB CHAMBER SUPPORT RH R750 NON SERVICEABLE PART
4 1 BRACKET COMB CHAMBER SUPPORT LH R750 NON SERVICEABLE PART
5 2 10458 BRACKET FRONT MOUNT RHFE
6 2 10751 WHEEL KIT RHFE750/IBOF
7 2 10778 GLASS RETAINER SPRING KIT RHFE750
8 1 10232 PANEL AIR DIVERTER RH RHFE750
9 1 10231 PANEL AIR DIVERTER LH RHFE750
10 1 10742Z PANEL AIR GUIDE LOWER US BLACK
11 1 COMBUSTION CHAMBER ASSEMBLY PAINTED R750 NON SERVICEABLE PART
12 2 10780 GLASS RETAINER SLIDE ASSEMBLY RHFE750
13 2 10390 GLASS RETAINER SLIDE COVER RHFE750
14 1 10224Z PANEL BURNER SHIELD PAINTED R750
15 1 10204 PANEL HEAT SHIELD REAR RHFE750
16 1 10427 PANEL HEAT SHIELD RH RHFE750
17 1 10431 PANEL HEAT SHIELD LH RHFE750
18 1 10432 PANEL COMB FAN FLUE DIVIDER
19 1 10208 PANEL FAN INFILL RHFE750
20 1 10205 PANEL OUTER RH RHFE750ETR
21 1 10206 PANEL OUTER LH RHFE750ETR
22 1 10263 PANEL COMB FAN INLET "A"
23 1 10264 PANEL REAR AIR INLET "B"
24 1 10781 COMBUSTION FAN COVER RHFE750
25 1 10213 PANEL COVER FLUE OUTLET
26 1 10869 PANEL COVER TRANS RHFE
27 1 10207 TOP PANEL RHFE ENGINE ASSEMBLY
28 1 10296Z LOUVER SIDE SUPPORT RH BLACK 750
29 1 10297Z LOUVER SIDE SUPPORT LH BLACK 750
30
2 10752 LOUVER HINGE KIT
KIT CONTAINS 1 x UPPER AND
1 x LOWER HINGE
31
32
1 10750 DOOR LATCH KIT CONTAINS 4 x LATCHES
33 1 10782 COMB CHAMBER GLASS ASSEMBLY RHFE750
34 2 10783 LOUVER SIDE ASSEMBLY RHFE750
35 2 10784 SCREEN KIT RHFE750
36 1 10785 WAX ELEMENT ASSEMBLY RHFE750
37 1 10786 MAIN PCB BRACKET ASSEMBLY RHFE750
38 1 10418 BRACKET REAR BURNER SUPPORT RHFE
39 1 10255 BRACKET RECEIVER RHFE750
40 1 10226 BRACKET INJECTOR SUPPORT RHFE750
41 3 10462 PACKING INJECTOR BLOCK
42 2 10753 INJECTOR BLOCK KIT REAR RHFE750
43 1 10754 INJECTOR BLOCK KIT FRONT RHFE750
44 2 7185 INJECTOR 1.45 NG **
44 2 5436 INJECTOR 0.9 LPG **
45 1 5425 INJECTOR 1.75 NG **
45 1 5548 INJECTOR 1.05 LPG **
46 1 10413 BRACKET TRANSFORMER MOUNT RHFE
47 1 10275A BURNER BRAY 450 NG + BUSH NG **
47 1 10277A BURNER BRAY 450 LP Ø5.0 LPG **
ITEM QTY PART NO. DESCRIPTION COMMENTS
** Always refer to the data plate for correct information.
