Renesas SH7201 User Manual
Page 25
JA5
Pin
Header Name
CPU board
Signal Name
Device Pin
Pin
Header Name
CPU board
Signal Name
Device Pin
1 AD4
AN4
90
13 Reserved
2 AD5
AN5
91
14 Reserved
3 AD6
AN6
92**
(R8) 15 Reserved
4 AD7
AN7
93**
(R11) 16 Reserved
5 CAN1TX
CTx0
50
17 Reserved
6 CAN1RX
CRx0
51
18 Reserved
7 CAN2TX
CTx1
52
19 Reserved
8 CAN2TX
CTx1
54
20 Reserved
9 Reserved
21 Reserved
10 Reserved
22 Reserved
11 Reserved
23 Reserved
12 Reserved
24 Reserved
Table 8-8: JA5 Standard Generic Header
JA6
Pin
Header Name
CPU board
Signal Name
Device Pin
Pin
Header Name
CPU board
Signal Name
Device Pin
1 DREQ
DREQ3
46
13 Reserved
2 DACK
DACK3
47
14 Reserved
3 TEND
DTEND3
49
15 Reserved
4 STBYn
DACT3
48
16 Reserved
5 RS232TX
RS232TX
(R60)**** 17 Reserved
6 RS232RX
RS232RX
(R70)**** 18 Reserved
7 SCIbRX
RxD1
110
19 Reserved
8 SCIbTX
TxD1
111
20 Reserved
9 SCIcTX
TxD4
117
21 Reserved
10 SCIbCX
SCK1
109
22 Reserved
11 SCIcCK
SCK4
115
23 Reserved
12 SCIcRX
RxD4
116
24 Reserved
Table 8-9: JA6 Standard Generic Header
**** This signal is only connected to the named link, which is not fitted to the board. For details refer to the RSKSH7201 circuit schematics
page 5
