J2
Pin Circuit Net Name Device
Pin
Pin Circuit Net Name Device
Pin
1 GND - 23 SDCKE 67
2 DREQ3 46 24 LED1 68
3 DACK3 47 25 DLCDE 69
4 DACT3 48 26 DLCDRS 70
5 DTEND3 49 27 WR1n 71
6 CTx0 50 28 WR0n_WRn 72
7 CRx0 51 29 RDn 73
8 CTx1 52 30 GND -
9 UC_VCC - 31 SDCS0n 75
10 CRx1 54 32 UC_VCC -
11 GND - 33 PTCK 77
12 IRQ3n 56 34 PTRX 78
13 IRQ2n 57 35 PTTX 79
14 IRQ1n 58 36 CS3n_TRISTn 80
15 IRQ0n 59 37 CS2n_ADTRGn 81
16 LED3 60 38 CS1n 82
17 LED2 61 39 CS0n 83
18 DQM1 62 40 AVCC -
19 DQM0 63 41 VREF -
20 SDWEn 64 42 ADPOT_AN0 86
21 SDCASn 65 43 AN1 87
22 SDRASn 66 44 AN2 88
Table 8-2: J2 microcontroller header
