Ruby Tech GS-1216L User Manual

Page 2

Software Upgrade

---Supports firmware upgrade via web GUI

802.1x network access security

---Provides multi-host authentication based on port-based
---Provides MAC based authentication with Radius server

SNMPv1, v2c Network Management

---MIB Files: MIB II(RFC1213), Bridge MIB(RFC1493), Interface Group MIB(RFC 2863)
RoHS Compliance
LED Description

Hardware Spec.

Packing Information

G
i

w
i

Gigabit Switch

Web Smart Switch

LED Color Function
Global POWER Green -Lit when +5V power is coming up
Global CPU Green -Blinks when CPU is active
Port 1-16 LINK/ACT Green -Lit when connection with remote device is good
-Blinks when any traffic is present
Port 1-16 10/100/1000 Green/Amber -Lit Green when TP link on 1000Mbps speed
Mbps -Lit Amber when TP link on 100Mbps speed
-Off when 10Mbps or no link occur
Port 13-16 SFP Green -Lit when SFP connection with remote device is good
-Blinks when any traffic is present

100~240 VAC

Frequency 50~60 Hz

Consumption 20W

Ambient Temperature 0 to 40 C

Humidity 10% to 90%

Dimensions 44(H) x 442(W) x 170.3(D) mm

Weight 2.4kg

Feature Detailed Description

Voltage

Safety PSU comply with UL

Carton Dimensions(mm) pcs/Carton N.W (KG) G.W (KG)

530 x 512 x 345 5 16 17

RUB

TECH

Networking & Communications

GS-1216L: 16-Port GbE Web Smart Switch with 4 SFP Dual Media

Note:
We recommend the SFP transceiver from the following vendors:
1. Ruby Tech Corporation
2. Agilient Technologies
3. AVAGO Technologies
4. Finisar Corporation

Ruby Tech Corp.
3F, No.1, Lane 50, Nan Kang Road, Sec.3, Taipei, Taiwan http://www.rubytech.com.tw
TEL:886-2-2785-3961 FAX:886-2-2786-3012 E-mail [email protected]

2008-07.25 Version A

Technical information listed is subject to change without prior notice. All brand names and trademarks are property of their respective owners.

Optional SFP Module
SFP.LC 1000Base-SX GE SFP Fiber Module, LC Multi-Mode 850nm
SFP.LC.M2 1000Base-SX GE SFP Fiber Module, LC Multi-Mode 1310nm 2km

Ordering Information
