6) (GET STATUS OPTION: Gets menu and installer OPTION data.)
Order Data Size Output Remarks
1 ENERGY MODE 1byte 1: STANDARD 2: MODE 1
3: MODE 2 4: MODE 3
5: AUTO
2 ORBITER 1byte 0:OFF 1: ON
3 MASK CONTROL 1byte 0:OFF 1: ON
4 AUDIO OUT 1byte 1:FIXED 2: VARIABLE
5 SCREEN MASK 1byte 0: OFF
2: INVERSE 3: WHITE
4: RED 5: GREEN
6: BLUE 7: YELLOW
6 SIDEBAR ADJ. 1byte 1: NORMAL 2: OVERLAY1
3: OVERLAY2
7 R. SIDEBAR ADJ. LEVEL 3byte 000 to 255
8 G. SIDEBAR ADJ. LEVEL 3byte 000 to 255
9 B. SIDEBAR ADJ. LEVEL 3byte 000 to 255
10 2 x 2 1byte 0:OFF 1: ON
11 2 x 2 LAYOUT & TYPE 1byte 1: NORMAL &UP LEFT
2: NORMAL &DOWN LEFT
3: NORMAL &UP RIGHT
4: NORMAL &DOWN RIGHT
5: ADJUSTED &UP LEFT
6: ADJUSTED &DOWN LEFT
7: ADJUSTED &UP RIGHT
8: ADJUSTED & DOWN RIGHT
12 MIRROR MODE 1byte 0:OFF 1: X 2: Y 3:XY
13 OSD 1byte 0:OFF 1: ON
14 FRONT INDICATOR 1byte 0:OFF 1: ON
15 FAN CONTROL 1byte 1: AUTO 2: MAX
16 COLOR MODE 1byte 1: NORMAL 2: ISF
17 RUNCO PRO UNDERSCAN 1byte 0:OFF 1: ON
18 RUNCO PRO COLOR OFF 1byte 0:DISABLE 1: ENABLE
19 FRC 1byte 1: MODE1 2: MODE2
3: MODE3
20 Dummy data 3byte
21 Input function data (main) 3byte
22 Sceen size data 1byte
23 Check sum 2byte
• 21and 22 output the same contents as GST items 3 and 5.
Total 34 Byte
