29
2) (GET PICTURE DATA: Gets installer/Picture data.)
Order Data Contents Size Remarks
1 CONTRAST 3byte #
2 BRIGHTNESS 3byte #
3 C. DETAIL R (RED) 3byte #
4 C. DETAIL Y (YELLOW) 3byte #
5 C. DETAIL G (GREEN) 3byte #
6 C. DETAIL C (CYAN) 3byte #
7 C. DETAIL B (BLUE) 3byte #
8 C. DETAIL M (MAGENTA) 3byte #
9 H SHARPEN 3byte Outputs dummy data for video signal. #
10 V SHARPEN 3byte Outputs dummy data for video signal. #
11 COLOR 3byte Outputs dummy data for PC signal. #
12 TINT 3byte Outputs dummy data for PC signal. #
13 SHARPNESS 3byte Outputs dummy data for PC signal. #
14 Input function data (main) 3byte
15 Screen size data 1byte
16 Check sum 2byte
• 7 and 8 output the same contents as GST items 3 and 5.
• When the type of # signal is not set, dummy data is output.
3) (GET WHITE BAL. DATA: Gets installer/WHITE BAL. data.)
Order Data Size Remarks
1 R. GAIN 3byte #
2 G. GAIN 3byte #
3 B. GAIN 3byte #
4 R. OFFSET 3byte #
5 G. OFFSET 3byte #
6 B. OFFSET 3byte #
7 Input function data (main) 3byte
8 Screen size data 1byte
9 Check sum 2byte
• 7 and 8 output the same contents as GST items 3 and 5.
• When the type of # signal is not set, dummy data is output.
4) (GET POSITION DATA: Gets installer/SCREEN data.)
Order Data Size Remarks
1 H SHIFT 3byte #
2 V SHIFT 3byte #
3 H. SIZE 3byte #
4 V. SIZE 3byte #
5 FREQ. ADJ. 3byte Outputs dummy data for PC digital and Video signal. #
6 PHASE ADJ. 3byte Outputs dummy data for PC digital and Video signal. #
7 Input function data (main) 3byte
8 Screen size data 1byte
9 Check sum 2byte
• 7 and 8 output the same contents as GST items 3 and 5.
• When the type of # signal is not set, dummy data is output.
