25
2 Performing Marking
2-2 Loading the Workpiece
1 Open the cover.
2 Grasp the base on both sides and pull back toward you
to remove.
3 Place the workpiece so that the center of the place to
mark is aligned with the center of the scale.
Important!
Powder or dust on the adhesive sheet can reduce the
sheet's adhesive force, making it impossible to secure
material in place.
If the adhesive force has been reduced, then wash the
adhesive sheet. Washing the sheet revitalizes its adhe-
sive force. For information on how to clean the adhesive
sheet, take a look at "4 Maintenance", "Cleaning the Ad-
hesive Sheet."
Marking location
on the image Location where the workpiece
is placed on the base
Center
line
Center line
