9
4. Insert the supplied AC adapter’s
barrel plug into the AC 9V 440mA
jack on the back of the base.
5. Plug the other end of the short
modular cord into the wall plate
jack. Then move the power cord to
the right of the two tabs, align the
wall plate studs with the TAD’s key-
hole slots and slide the TAD down-
ward to secure it.
6. Slide the handset clip up and out of
its retaining slot, rotate it 180°, then
slide the clip back into its slot.
7. Plug the other end of the coiled
cord into the handset’s jack.
8. Place the handset into the cradle.
9. Plug the adapter into a standard
AC outlet.
Illus. of AC 9V 440mA jack. Show-
ing barrel plug about to be inserted
into jack and modular cord already
connected.
Illus. of wall plate alignment
and power cord attachment.
Illus. showing clip being re-
moved and re-inserted.
Illus. showing coiled cord
connection to handset.
