7
MOUNTING THE TAD
Select a location that is near both a
modular telephone jack and an AC out-
let. You can place the TAD on a desk, or
mount it on a wall plate or directly on a
wall.
Your TAD-764 connects directly to a
modular telephone line jack. If the jack
is not a modular jack, you must update
the wiring. You can convert the wiring
yourself, using jacks and adapters
available at your local RadioShack
store. Or, you can let the telephone
company update the wiring for you. The
USOC number of the jack to be installed
is RJ11C, or RJ11W for a wall plate
jack.
Note: Adjust VOLUME (located on the
TAD’s right side) to the middle position
before connecting power.
Caution: The supplied adapter sup-
plies 9 volts AC, delivers at least 440
milliamps, and has a plug which proper-
ly fits the TAD’s
AC 9V 440mA jack. Us-
ing an adapter that does not meet these
specifications might damage the TAD or
the adapter.
On a Desk Top
Follow these steps when you place the
TAD on a desk, shelf, or table.
1. Plug one end of the supplied long
modular cord into the TO LINE jack
on the back of the base.
2. Plug the modular cord’s other end
into a modular phone line jack.
3. Plug one end of the supplied coiled
handset cord into the jack on the
base’s bottom and route the cord
into the groove near it. Plug the
other end into the handset’s jack.
4. Place the handset in the cradle.
5. Insert the supplied AC adapter’s
barrel plug into the AC 9V 440mA
jack on the back of the base.
Illus. of VOLUME
switch.
Illus of TO LINE jack and
end of modular cord about
to be inserted into jack.
Other connections are not
yet made.
Illus. of coiled handset
cord and base
Illus. of AC 9V 440mA jack.
Show barrel plug about to be
inserted into jack. Show
modular cord already con-
