On a Wall
You need two flat-head wood screws
(not supplied) with heads that fit into the
keyhole slots on the bottom of the TAD.
1. Drill two holes 3 15 /
16
inches (100
mm) apart. Then thread a screw
into each hole letting the heads
extend about
3 /
16
of an inch (5 mm)
from the wall.
2. Plug one end of the supplied long
modular cord into the TO LINE jack
on the back of the base.
3. Route the cord into the groove on
the phone’s base.
4. Plug one end of the supplied coiled
cord into the jack on the bottom of
the base and route the cord into the
groove beside the jack.
5. Insert the supplied AC adapter’s
barrel plug into the AC 9V 440mA
jack on the back of the base.
6. With the power cord moved to the
right of the two tabs and the modu-
lar cord hanging straight down from
the groove, align the two screws
with the TAD’s keyhole slots and
slide the TAD downward to secure
it.
Illus. showing screw
positions on the
Illus of TO LINE jack and
end of modular cord about
to be inserted into jack. Oth-
er connections are not yet
made.
Illus. showing routing of
modular cord.
Illus. showing routing of
coiled cord before it is
plugged into the handset.
Illus. of AC 9V 440mA jack.
Showing barrel plug about
to be inserted into jack and
modular cord already con-
nected.
Illus. showing bottom of base,
keyhole slots, screws.
Also, show power cord and
modular cord hanging down.
