83
Various Settings
Connecting the HP207 to a V-LINK compatible image device
allows you to control the images with the HP207.
To prevent malfunction and/or damage to speakers
or other devices, always turn down the volume, and
turn off the power on all devices before making any
connections.
V-LINK
V-LINK ( ) is functionality promoted by Roland
that allows linked performance of music and visual material.
By using V-LINK-compatible video equipment, visual effects
can be easily liked to, and made part of the expressive
elements of a performance.
How to Use the V-LINK
1. Hold down the [Effects] button and press the
[3D] button.
The HP207 will enter Function mode.
2. Use the [ ▲ ] [ ▼ ] buttons to select “V-LINK.”
fig.d-FuncMenu-VLink.eps
3. Press the [ ] button.
The following appears in the display.
fig.d-VLinkOff.eps
4. Press the [-] or [+] button to switch the V-LINK
function On or off.
5. Press the [Piano Designer] button twice to
return to the tone select screen.
When the V-LINK function is on, the V-LINK icon appears
on the screen.
fig.VLinkIcon.eps
You can control images using the twelve keys at the left
end of the keyboard.
While V-LINK is switched on, no sound is produced
when you press any of the twelve keys at the left
end of the keyboard.
To disengage V-LINK, repeat steps 1–3 on the preceding
page, and choose “off” in step 4.
Other Settings
Using the V-LINK Function (V-LINK)
NOTE
Setting Explanation
On The V-LINK function is switched on.
Off The V-LINK function is switched off.
C1 D1 E1 F1 G1 A0
A0 – G1#
B0
NOTE
