ROTEL RC-1550 User Manual
Page 4
4
RC-1550
Figure 3:
Input and Output Connections
Branchements des entrées et des sorties
Ein- und Ausgangsanschlüsse
Conexiones de Entrada y Salida
Het aansluitschema
Collegamenti di ingresso ed uscita
Anslutningar för in- och utsignaler
иУ‰ТУВ‰ЛМВМЛВ ‚ıУ‰У‚ Л ‚˚ıУ‰У‚
R L
GND
PH0NO
ROTEL RC-1550
ROTEL RB-1572
RECORDER
INPUT
R L
OUTPUT
R L
CD PLAYER
OUTPUT
R L
