Caution – Renesas M306V0T-RPD-E User Manual
Page 29
( 27 / 48 )
Connect FLX120-RPD with M306V0T-RPD-E. Figure 5.2 shows how to connect M306V0T-RPD-
E and FLX120-RPD.
Figure 5.2 Connecting M306V0T-RPD-E and FLX120-RPD
CAUTION
Note on Connecting the Cable:
• Always shut OFF power before connecting the cable. The power ON state could
destroy internal circuits.
