Ruby Tech GS-2108C User Manual

Page 2

STP/RSTP
---802.1d/1w/1s STP

Network Security

---802.1x access control
---Management Access Policy Control
(ACL)

SNMPv1,v2c Network Management

---RFC 1213 MIB (MIB-II)
Interface MIB
Address Translation MIB
IP MIB
ICMP MIB
TCP MIB
UDP MIB
SNMP MIB
---RFC 1757 RMON MIB
Statistics Group 1
History Group 2
Alarm Group 3
Event Group 9
---RFC 1493 Bridge MIB
---RFC 1643 Ethernet MIB
---Enterprise MIB

Overview

The GS-2108 is an L2 managed Gigabit
switch that supports SNMP, Web UI and
CLI management interface. It is equipped
with 8 Gigabit TP ports and 2 of which are
dual media ports that accommodate
optional 10/100/1000Base-T or SFP
modules. In addition, the switch
implements the QoS (Quality of Service),
Mac Filtering Policy, Port Mirror, VLAN and
full L2 protocol. It is suitable for workgroups
or WAN edge application.

G
i

w
i

Gigabit Switch

L2 Managed Switch

RUB

TECH

Networking & Communications

Broadcast/Multicast Storm control

To limit too many broadcast/multicast flooding in the network, broadcast/

multicast storm control is used to

traffic. Threshold values are

restrict excess

available to control the rate limit for each port. Packets are discarded if the
count exceeds the configured upper threshold.

Technical Specifications

LED Description:

Diagnostic LED:

Network Interface:

Cable and Maximum Length:

Hardware Specifications:

Packing Information

Ordering Information

GS-2108C: 8-Port GbE L2 Managed Switch with 2 SFP Dual Media
Optional SFP Module

Note:
We recommend the SFP transceiver from the following vendors:
1. Ruby Tech Corporation 2. Agilient Technologies 3. AVAGO Technologies
4. Finisar Corporation

LED Color Function
Global POWER Green -Lit when +5V power is coming up
Global CPU Green -Blinks when CPU is active
Port LINK/ACT Green -Lit when connection with remote device
1-8 is good
-Blinks when any traffic is present
Port 10/100/ Green/ -Lit Green when TP link on 1000Mbps
1-8 1000Mbps Amber speed
-Lit Amber when TP link on 100Mbps
speed
-Off when 10Mbps or no link occurs
Port SFP Green -Lit when SFP connection with remote
7,8 device is good
-Blinks when any traffic is present

Dimensions 44(H) x 217(W) x 132.7(D) mm

Weight 1kg

Feature Detailed Description

Voltage 100~240 VAC
Frequency 50~60 Hz
Consumption 13W
Ambient Temperature 0 to 40 C

Humidity 5% to 90%

Safety UL
Complies with FCC Part 15 Class A & CE
Mark

System LED Power
10/100/1000M TP Port Per Port LED Link/Act, 10/100/1000Mbps
Gigabit SFP Module LED SFP

Configuration Connector Port
10/100/1000Mbps TP Jack (RJ-45) TP(RJ-45) 1 to 8
1000Mbps SFP Fiber Module SFP 7, 8

TP Cat. 5 UTP cable, up to 100m
1000Base-SX SC M-M Up to 220/275/500/550m,
which depends on Multi-Mode
Fiber type
1000Base-LX SC S-M Single-Mode Fiber, up to10/30/50Km
1000Base-LX WDM SC S-M Single-Mode Single Fiber, Bidi 20Km

Carton Dimensions (mm) pcs/Carton N.W (KG) G.W (KG)

495x480x335 10 17 18

530x512x345 12 20 21

Ruby Tech Corp.
3F, No.1, Lane 50, Nan Kang Road, Sec.3, Taipei, Taiwan http://www.rubytech.com.tw
TEL:886-2-2785-3961 FAX:886-2-2786-3012 E-mail [email protected]

2008-07.25 Version A

Technical information listed is subject to change without prior notice. All brand names and trademarks are property of their respective owners.

SFP.LC 1000Base-SX GE SFP Fiber Module,
LC Multi-Mode 850nm
SFP.LC.M2 1000Base-SX GE SFP Fiber Module,
LC Multi-Mode 1310nm 2km
