11
Before You Start Playing
■ Using the Music Holders
You can use the holders to hold pages in place.
When not using the holders, leave them folded down.
* HP103-PE has not music holders.
fig.mu_stand4
Connecting Headphones
The HP103 has two jacks for plugging in headphones. This
allows two people to listen through headphones
simultaneously, making it very useful for lessons and when
performing piano pieces for four hands. Additionally, this
allows you to play without having to worry about bothering
others around you, even at night.
Plug the headphones into the Phones jack located at the
bottom left of the piano.
When headphones are connected, the [ (Headphones)]
indicator (p. 8) lights up, and sounds stop playing from
the speakers of the HP103.
The headphone volume is adjusted by the [Volume]
knob (p. 12) of the HP103.
fig.00-04.e
NOTE
Use Stereo headphones.
Some notes on using headphones
• To prevent damage to the cord, handle the headphones only by
the headset or the plug.
• Connecting the headphones when the volume of connected
equipment is turned up may result in damage to the
headphones. Lower the volume on the HP103 before plugging
in the headphones.
• Listening at excessively high volume levels will not only
damage the headphones, but may also cause hearing loss. Use
the headphones at a moderate volume level.
■ Using the Headphones Hook
Whenever you are not using the headphones, you can hang
them on the headphone hook at the lower left of the HP103.
Attaching the Headphone Hook
Press and twist the headphone hook included with the
HP103 into the hole in the bottom of the HP103 (refer to the
figure below). Turn the wing nut of headphone hook to
secure the headphone hook.
Turning the Power On and Off
NOTE
Once the connections have been completed, turn on
power to your various devices in the order specified. By
turning on devices in the wrong order, you risk causing
malfunction and/or damage to speakers and other
devices.
To turn the power on, turn the [Volume] knob all the
way down, and then press the [Power On] switch.
The power will turn on, and the Power indicator at the
left front of the HP103 will light.
After a few seconds, you will be able to play the
keyboard to produce sound.
Use the [Volume] knob to adjust the volume.
* This unit is equipped with a protection circuit. A brief interval
(a few seconds) after power up is required before the unit will
operate normally.
fig.00-06.e
To turn the power off, turn the [Volume] knob all the
way to the left, and press the [Power On] switch.
The Power indicator at the left front of the HP103 will go
dark, and the power will be turned off.
* If you need to turn off the power completely, first turn off the
[POWER] switch, then unplug the power cord from the power
outlet. Refer to “Power Supply” (p. 5).
Phones jack x 2
Headphone Hook
Wing Nut
Power Indicator
Power On
