Before you begin
Since the SH-201 does not contain speakers, it cannot produce sound by itself. In order to produce sound, you
must connect monitor speakers, a stereo set or other audio system, or headphones.
Connecting monitor speakers or a stereo set
Use the appropriate cables to connect the OUTPUT jacks on the SH-201’s rear panel to your monitor speakers
or stereo set.
* In order to take full advantage of the SH-201’s capabilities, we recommend that you make connections in stereo.
If you’re making connections in monaural, connect to the OUTPUT L (MONO) jack.
Connecting headphones
Connect your stereo headphones to the PHONES jack on the rear panel of the SH-201.
* Sound will be sent out from the OUTPUT jacks even if headphones are connected.
Connecting headphones or speakers
Monitor Speakers
(powered)
Power Amplifier
Mixer etc.
Stereo Headphones
