L202, L203 faulty

Check resistance from L202, L203 to the earphone pads normal 0

Check the resistance also from L202,L203 to ground and between both lines (normal high resistance >1M

)

Speaker

No / quiet / distorted receiving audio signal

Check the mechanic of speaker, contacts, membrane, soiling

Check resistance of speaker (about 30

)

Microphone

No / quiet / distorted transmitting audio signal

Check contacts of microphone
Check resistance of microphone (about 800

)

Check the microphone voltage 1,7V DC on C242

(wintesla/ Testing/ Audio/ internal/ Loop on)

Check the audio signal on C258 and C259

X503

Check microphone spring contacts

Check spring contacts to the board (change connector if bent)

Clean the contact pads on the board

N200 COBBA faulty

Check VBB 2,8V DC on C117 near to CCONT

Check VCOBBA 2,8V DC C148 near to COBBA

Check COBBACKL 13MHz 3,2Vpp on J 201

Check COBBA reset impulse during the initialisation routine on J343 (see the diagram "CONBBA RESET")

Change COBBA and write the IMEI and SIM-LOC DATA back to the phone

If the error persist the MAD or the Board (PCB) should be the reason

SWAP the handset because MAD is not changeable

Note! Rewrite SIMLOCK and IMEI entries with use of the Nokia security SW (SSSW) and make a SW-update or send
this phones to the SACE, if this procedure is not permitted to you
