D303 Eeprom faulty
• Check with wintesla if IMEI or product data are corrupted
• Check 2,8V DC on pin 8 of Eeprom
• Don't use the "Full factory set" with wintesla, otherwise the Original IMEI will be change to
"65656565…"
• Change the Eeprom if it's permitted to you and write all ID data (IMEI, product code…) back
• If you aren't allowed to change the Eeprom and the IMEI is missing, write a note with a little
comment, and send it together with the phone to the SACE
Note! Rewrite SIMLOCK and IMEI entries with use of the Nokia security SW (SSSW) and make a SW-update or send
this phones to the SACE, if this procedure is not permitted to you
Clock time or user settings problems
Clock time / Ringing tone is to fast or to slowly
32,786KHz Sleep oscillator B100
• Check that the sleepclk 32.768KHz square wave frequency on pin C149 isn't higher or lower
• Check the crystal B100, C147, C148, C153, N100
• View also the Service Bulletin 017 (capacitors C148, C153 change the value)
Clock time problems / wrong ringingtone speed
check 32,768KHz
clock frequency on
C149 CCONT
Check soldering or
change B100,
C147,C148,
C153,N100
