Index

IN-2

8600-A2-GN20-20

October 1997

I

installation site consideration, 2-3

installation tasks

connecting to a modem for remote management,

2-27

connecting to a POTS splitter, 2-23

connecting to a terminal or computer, 2-26

connecting to an MDF, 2-23

connecting to an SNMP management system, 2-25

connecting to Ethernet hubs or switches, 2-24

installing the chassis, 2-5

installing the DSL cards, 2-19

installing the MCC card, 2-18

summary of tasks, 2-4

supplying power, 2-13

verifying the installation, 2-21

installing the chassis

on a desktop or table, 2-5

rack with threaded screw holes, 2-10

rack without threaded screw holes, 2-12

interconnecting the stack, 2-5

L

LEDs

fan alarm, 4-2

on the 8600 chassis, A-1

on the MCC card, A-2

power, 4-1

system alarm, 4-2

load sharing, 1-4

M

Main Distributing Frame (MDF), 2-23

making cable connections, 2-22

Management Communications Controller (MCC) card,

1-3

installing the card, 2-18

removing the card, 2-19

setting the IP address, 3-1

setting the subnet mask, 3-1

management information bases (MIBs), 1-4

Media Access Control (MAC) address, 2-19, 2-20

modem connection, 2-27

N

National Equipment Building Standards (NEBS), 2-7

O

operating environment specifications, C-2

organization of guide, iv

P

package contents

associated hardware, 2-2

chassis, 2-2

documentation, 2-2

physical dimensions, C-1

pinouts

8-pin modular asynchronous terminal, B-3

DB25 adapter, B-3

LAN/WAN connectors, B-2

management 10BaseT connector, B-1

management IN and OUT connectors, B-2

Telco 50-pin for DSL loops and POTS splitters, B-4

POTS Splitter, 1-1, 2-23

power

failure, 4-1

using a single dc power source, 2-13

using ac power with dc power backup, 2-16

using only ac power source, 2-16

using two dc power source, 2-14

power considerations, 2-3

power redundancy, 1-4

power specifications, C-2

pre-installation considerations, 2-3

R

rack mounting

with threaded screw holes, 2-10

without threaded screw holes, 2-12

related documents, v

remote configuration setup instructions, 3-1

Remote Termination Unit (RTU), 1-1

removing card

DSL card, 2-20

MCC card, 2-19
