C-1 8600-A2-GN20-20 October 1997
Technical Specifications
C
The following table lists the technical specifications for the HotWire 8600 DSLAM
chassis:
Specifications Criteria
Physical Dimensions Height: 4.7 inches
Width: 17.2 inches
Depth: 10.5 inches
Weight: 9 pounds
Three chassis can be safely placed on top of each
other on a desktop or table. In addition, a standard
7-foot EIA cabinet can hold a maximum of
14 chassis.
Interfaces H – 48V power (two pairs of screw terminals for
A and B inputs)
H Three 8-pin modular jacks for 10BaseT Network
Access Provider interfaces
H One 50-pin Telco connector for DSL Loop
interfaces
H One 8-pin modular jack for 10BaseT interface
for the MCC card
H Two 8-pin modular jacks for daisy-chained
control bus connection
H One 8-pin modular jack for a VT100 compatible
terminal (serial) connection
