Installing and Connecting the Hardware
2-9 8600-A2-GN20-20 October 1997
The software identifies each circuit card in the stack by a Slot Number. The
following illustration shows the designated number for each DSL card slot in a
stack.
1
2
3
97-15448-01
DSL
DSL
MCC
1
2
3
DSL
DSL
DSL
1
2
3
DSL
DSL
DSL
1
2
3
DSL
DSL
DSL
1
2
3
DSL
DSL
DSL
1
2
3
DSL
DSL
DSL
2
1
5
4
3
8
7
6
11
10
9
14
13
12
17
16
15
Assigned DSL Slot Numbers
Additional
Systems
Base
Chassis
3
2
1
3
2
1
3
2
1
3
2
1
3
2
1
3
2
1
Software
Assigned
Physically
Assigned
NOTE:
This illustration depicts a stack of six HotWire 8600 systems which is valid for
rack mounting. However, the same relationship of software-assigned slot
numbers applies to two stacks of three each, mounted on a desk or table top
and connected by a bus cable.
