Pinouts
B
8-Pin Modular Ethernet Connector for MCC
Management Connector Pinouts
The 8-pin interface for the MCC Management 10BaseT Ethernet connection has
the following pin assignments:
Pin Number
Use
1
TX Data +
2
TX Data –
3
RX Data +
4
Reserved
5
Reserved
6
RX Data –
7
Reserved
8
Reserved
