© National Instruments Corporation 47 NI 9144 User Guide and Specifications
0x3C CRC value
0x49 Calibration Gain Byte 2 – Channel 1
0x76 Data Byte
0x50 CRC value
0x4A Calibration Gain LSB – Channel 1
0x3C Data Byte
0xF6 CRC value
0x81 ADC Mode Configuration Byte – Channel 2
0x01 Data Byte
0xCE CRC value
0x9F Mode/Range Configuration – Channel 2
0x01 Data Byte
0x4E CRC value
0x84 Calibration Offset MSB – Channel 2
0x7F Data Byte
0xDC CRC value
0x85 Calibration Offset Byte 2 – Channel 2
0xFF Data Byte
0x3E CRC value
0x86 Calibration Offset LSB – Channel 2
0xC8 Data Byte
0xC2 CRC value
0x88 Calibration Gain MSB – Channel 2
0x6C Data Byte
0x96 CRC value
0x89 Calibration Gain Byte 2 – Channel 2
0xB0 Data Byte
Table 41. NI 9219 Configuration 1: Command Bytes (Continued)
Command Byte Value Description
