Chapter 6: VEA-6830 Video Distribution Amplifier Module Specifications
50 6800/7000 Series - Distribution and Routing Products Installation and Operation Manual
Performance
Differential Gain
Temperature
Item Specification
Gain Range -3 dB to + 3 dB
Gain Stability 0.02 dB per 10 C
Frequency Response • 0.02 dB to 5 MHz
• 0.1 dB to 10 MHz
• 0.1 dB to 10 MHz
• +0 / -0.2 dB at 15 MHz
• -0.5 dB at 20 MHz typ.
• -3 dB at 30 MHz
Item Specification
Differential Gain
(10-90% APL) 0.10%
Differential Phase
(10-90% APL) 0.15
Line Rate Window
Tilt 0.25%
Field Rate Window
Tilt 0.25%
S/N Ratio (RMS
noise/0.714V) 60 dB to 20 MHz unweighted
Hum 1 mVp-p
Equalization Range 0 to 1000 ft (300 m) Belden 8281, or equivalent
Response • 0.05 dB to 5 MHz
• 0.15 dB to 10 MHz
Item Specification
Performance 41 ° to 104°F (5° to 40° C)
Operating 32 ° to 122°F (0° to 50° C)
Power Dissipation 2 W
