Chapter 10: VSE-6802 Serial Equalizing Distribution Amplifier Module Specification
100 6800/7000 Series - Distribution and Routing Products Installation and Operation Manual
LED Indicators
LED Name Indication
D1 (Green) Data Present Data is present at the input.
D3 (Red) No Data No data is at the input.
D5 (Red) No Locked The input data cannot be locked
by the reclock stage.
D2 (Yellow) 143 MHz The input data is re-locked on 143
MHz.
D4 (Yellow) 177 MHz The input data is re-locked on 177
MHz.
D6 (Yellow) 270 MHz The input data is re-locked on 270
MHz.
D7 (Yellow) 360 MHz The input data is re-locked on 360
MHz.
D8 (Yellow) 540 MHz The input data is re-locked on 540
MHz.
