Specifications Chapter 12: VSM-6802 Digital Composite Video Signal Monitor Module
Level 1 V
DC Offset ± 100 mV
Frequency Response ± 0.25 dB to 5 MHz
Differential Gain 1.5%
Differential Phase 2 °
Chrominance-
Luminance Delay
Inequality < ± 10 ns
Total Power
Dissipation • Positive rail: 2.2 W
• Negative rail: 2.8 W
• Total: 5.0 W
Item Specification
