Chapter 4: USM-6800 PAL/NTSC Monitoring Encoder Module Specifications
36 6800/7000 Series - Distribution and Routing Products Installation and Operation Manual
Composite Analog Outputs
Component Analog Outputs
Item Specification
Number of Outputs 4
Type NTSC or PAL (input line rate dependent)
Impedance 75 W
Return Loss 36 dB to 5 MHz
Signal Level 1.0 Vp-p ± 10%
DC Offset ± 100 mV
Differential Gain 1.5%
Differential Phase 1.5%
Chroma-Luma Delay ± 10 ns
Power Dissipation • Positive rail: 2.8 W
• Negative rail: 2.6 W
• Total: 5.4 W
Item Specification
Number of CAV outputs 1 of GBR or Y, R-Y, B-Y
Impedance 75 W
Gain Adjustable Range 700 mV, -10% to +50% on R-Y and B-Y
±10% on RGB
DC Offset ±100 mV
Chroma/Lum. Delay Error ±3 ns
Return Loss >36 dB to 5 MHz on all outputs
Quantizing 8 bits
