Model FA510 Network Card Installation Guide

The Model FA510 Network Card is hot swappable, which means it can be
inserted into a PC that is either turned off or powered on.

1. Insert the Model FA510 Network Card into the CardBus slot as

illustrated in the figure.

Some PCs have two CardBus slots. The Model FA510 Network Card can
be inserted into either slot.

2. Insert the RJ-45 adapter cable into the connector on the edge of the

network card.

3. Insert the Category 5 10/100 Mbps UTP cable into the RJ-45 adapter

cable.

4. If you have chosen to install the card with the power turned off, turn on

the power to the PC.

Install the Network Card

Model FA510

Network Card and

RJ-45 adapter

cable
