CHAPTER 1 MATWorX
2. Hardware Connections
There are three ways in connecting a PC to the PBX.
(1) Direct Connection
Connect PC serial port to the PBX serial port us-
ing a MAT cable. Data throughput can reach
19200 bps.
(2) Modem Connection
Connect PC modem to the PBX built-in modem
via the public network.
This connection can be used for remote access.
The default setting of data throughput is 9600 bps,
however, you can reach 19200 bps by setting of
CM40 Y=08>1:5.
(3) LAN Connection
Connect your PC to the PBX via the Ethernet
LAN.
