— 10 —

Dip Switch Setting

IMC-101 series DIP switch

Dip Switch 1 (Default: Off )
ON: Enables the PORT Alarm. If the port’s link fails, the

relay will form an open circuit and the fault LED will
light up.

Off: Disables the corresponding PORT Alarm. The relay

will form a closed circuit and the Fault LED will never
light up.

Dip Switch 2 (Default: ON )
ON: Enable full duplex for 100BaseFX
Off: Disables full duplex for 100BaseFX

Dip Switch 3
Reserved for future use

To activate the updated setting of dip switch, you need to power off then
power on the switch.

LED Indicators

The front panel of MOXA Industrial Media Converter contains several
LED indicators. The function of each LED is described in the table
below.

LED Color State

Description

On

Power is being supplied to power
input P1

PWR1

AMBER

Off

Power is not being supplied to
power input P1

On

Power is being supplied to power
input P2

PWR2

AMBER

Off

Power is not being supplied to
power input P2

On

When the corresponding PORT
alarm is enabled, and the port’s
link is inactive.

Fault

RED

Off

When the corresponding PORT
alarm is enabled and the port’s
link is active, or when the
corresponding PORT alarm is
disabled.

On

TP port’s 10 Mbps link is active

Blinking

Data is being transmitted at 10
Mbps

10M

GREEN

Off

TP Port’s 10 Mbps link is inactive

On

TP port’s 100 Mbps link is active

100M

(TP)

GREEN

Blinking

Data is being transmitted at 100
Mbps
