The Router’s Rear Panel
The rear panel of the DG834GT 108 Mbps Super Wireless ADSL Router ( Figure 2-3 ) contains
port connections.
Table 2-1. LED Descriptions
Label Activity Description
Power On
Off Power is supplied to the router.
Power is not supplied to the router.
Test On
Off The system is initializing.
The system is ready and running.
Wireless On
Off Indicates that the Wireless port is initialized.
The Wireless Access Point is turned off.
Internet Blink -- Amber
On -- Green
Blink -- Green Indicates ADSL training.
The Internet port has detected a link with an attached device.
Data is being transmitted or received by the Internet port.
LAN On (Green)
Blink (Green)
On (Amber)
Blink (Amber)
Off The Local port has detected a link with a 100 Mbps device.
Data is being transmitted or received at 100 Mbps.
The Local port has detected a link with a 10 Mbps device.
Data is being transmitted or received at 10 Mbps.
No link is detected on this port.
