Reference Manual for the MR814v2 Cable/DSL Wireless Router
1-6 Introduction
The Router’s Front Panel
The front panel of the MR814v2 router contains the status LEDs described below.
Figure 1-1: MR814v2 Front Panel
You can use some of the LEDs to verify connections. Viewed from left to right, Table 1-1
describes the LEDs on the front panel of the router. These LEDs are green when lit.
Table 1-1. LED Descriptions
Label Activity Description
Power
On
Off Power is supplied to the router.
Power is not supplied to the router.
Internet
On
Blink The Internet (Wide Area Network) port has detected a link with an
attached device.
Data is being transmitted or received by the Internet port.
