Technical specifications
DN01154358 © Nokia Networks Oy 33 (40)
Issue 1-0 en Nokia Proprietary and Confidential
Indicator lights
DSL ADSL line status
HPNA (MW1324 only) HomePNA activity and status
ETH Ethernet activity and status
COL Ethernet collision
WLAN WLAN activity and status
STA M/MW startup
PWR Power on
Mechanical construction and power supply
Width 255 mm
Height 65 mm
Depth 230 mm
Weight 1 kg
Mains connection
Voltage 100 Vrms-240 Vrms AC (nominal values)
Frequency 50/60 Hz
Power consumption 10 W
Ambient confitions, EMC and safety
Operating temperature 5 to 45 ° C
Humidity 10% to 90%, non-condensing
EMC
M/MW complies with the following specifications provided that the device is connected to an earthed socket
outlet.
Emission EN55022: 1998 class B
Immunity EN55024: 1998
EMC EN300286–2: 1997, FCC part 15 class B
Overvoltage ITU-T K.21, FCC PART 68
Safety
Safety EN 60950, UL 1950, 3rd edition
