Preparations
DN01154358 © Nokia Networks Oy 11 (40)
Issue 1-0 en Nokia Proprietary and Confidential
Off ADSL/SHDSL link is down.
Blinks ADSL/SHDSL connection is being established.
On ADSL/SHDSL link is up.
Off No stations detected.
On Stations detected but no traffic.
Blinks Traffic detected at HPNA interface.
Off Ethernet is down.
On 10Base-T Ethernet is functional.
Blinks Traffic detected on Ethernet.
Blinks Collisions on the Ethernet. Note, that it is normal that some
collisions occur on the Ethernet.
Off No stations on the WLAN, or WLAN PC Card not inserted.
On Stations on the WLAN but no traffic.
Blinks Receives traffic through the WLAN interface.
Off OK
On Hardware malfunction.
Blinks The gateway is booting.
Off Power off.
On Power on.
Connectors and power switch
The gateway's power switch, mains connector and data connectors are located in
the back panel. For MW models, see figure 3. For M models, see figure 4.
DSL GREEN
GREEN HPNA (MW1324 only)
ETH GREEN
COL GREEN
GREEN (MW series only) WLAN
RED STA
PWR GREEN
