Nokia M/MW Gateways M1112, M1122, MW1112, MW1122, MW1324, MW1352

12 (40)

© Nokia Networks Oy

DN01154358

Nokia Proprietary and Confidential

Issue 1-0 en

Figure 3.

Back panel, MW models

Figure 4.

Back panel, M models

(MW1324 only)

DSL

Power switch

Ethernet

WLAN (PC card)

Command line interface (CLI)

Mains connector

HPNA

DSL

Power switch

Command line interface (CLI)

Mains connector

Ethernet ports
(ETH-1, ETH-2,
ETH-3, ETH-4)
