Nokia M/MW Gateways M1112, M1122, MW1112, MW1122, MW1324, MW1352
32 (40)
© Nokia Networks Oy
DN01154358
Nokia Proprietary and Confidential
Issue 1-0 en
Encapsulation
Ethernet compatible
Connector
RJ-12
Wireless LAN interface (MW models only)
Wireless LAN
IEEE 802.11b DSSS
Data connector
PC Card slot type 2
Routing
Routing protocols
RIPv1, RIPv2, and static routes
Other
NAPT, IGMP proxy, DHCP server, DHCP relay, DHCP client, DNS relay,
PPTP local tunnelling, PPPoE client
Class of Service
Weighted fair queueing
Firewall
Stateful inspection firewall
Bridging
Bridging
Self-learning bridge, bridges between all interfaces. Possibility to disable
bridging between WAN interfaces.
MAC table
1024 entries
Class of Service
Weighted fair queueing
Command line interface (CLI) for local management
Physical layer
Electrically RS-232, TxD, RxD and GND signals
Data format
Asynchronous, 8+no parity + 1 stop bit (8-N-1)
Bit rate
9600 bps
Flow control
None
CLI connector
RJ-45
Dedicated ATM management channel
Service categories
UBR
Encapsulations
RFC2684 ETH-LLC, RFC2684 IP-LLC, RFC2364 PPP-VC
IP addressing
Statically configured
Through IPCP when PPP over ATM is used
Routing
Static routes
RIPv1, RIPv2
Management protocols
Telnet/TCP/IP for command line interface,
TFTP/UDP/IP for software and configuration download, HTTP/web server
Management through payload
Management protocols
Telnet/TCP/IP for command line interface,
TFTP/UDP/IP for software and configuration download, HTTP/web server
