NILES AUDIO CORPORATION – 1-800-BUY-HIFI or 1-305-238-4373

21

SW10WM (WALL MOUNT) SUBWOOFER

The SW10WM Wall Mount subwoofer includes the following items:

Preconstruction package:

• 1 Ported cabinet (back box) with trim-out panel

• 1 set of installation brackets with screws

• 1 set of rubber feet

Installation package:

• 1 Baffle mounted passive driver

• 1 MicroPerf™ grille with frame

• 1 Template for subwoofer placement

TOOLS NEEDED:

• Pencil

• Drywall saw

• Phillips screwdriver

• Drill (and assorted bits)

• Wire strippers

• Tape measure

• Level (optional)

• Awl (optional)

• Staple gun (optional)

• Protective safety gear

• Tools suitable for cutting opening in the applicable flooring/wall material

CAUTION: ALWAYS CHECK FOR ELECTRICAL, HEATING, PLUMBING, CONDUIT, ETC., BEFORE CUTTING
INTO CEILINGS OR FLOORS.

Figure 5.

Niles SW10WM Wall Mount Subwoofer
