NILES AUDIO CORPORATION – 1-800-BUY-HIFI or 1-305-238-4373
9
7. Install Trim Out Panel to protect cabinet
from debris until trim out using the
supplied screws.
8. For trim out, remove Trim Out Panel.
9. Install the included floor grille into the cut-
out opening using the same screws from
the
Trim Out Panel.
OPTIONAL: The grille can be painted to match
most decors but should be painted before
installation. Additionally, paint the grille
separately from the loudspeaker frame. For
best results when painting the grille, use a spray
gun or airless sprayer. Thin the paint to prevent
clogging of the grille holes and apply several
light coats instead of one heavy one.
SW10JM INSTALLATION – FLOOR APPLICATION
(CONTINUED)
Cover
3" Screws
Floor
Hole Cut-out
Grille 3" Screws
Floor
Hole Cut-out
