Windows Setup 4-33
Step 9: Create Volume
For NEC Express5800/ft series, you need to create mirrors for all volumes. In case of creating a new
volume except for the one that stores the system partition, see “Hard Disk Configurations that can
be built on the NEC Express5800/ft series”on the separate User’s Guide.
For how to create or mirror volume, see the Online Help of Windows and “Step 6: Set Dual Disk
Configuration” (page 4-29).
IMPROTANT:
The creation of volume is available after the system opeation is started.
For creating volume, refer to “Hard Disk Configurations that can be built on the NEC
Express5800/ft series” in the separate User’s Guide.
Step 10: Set Network for NEC ESMPRO Agent
NEC ESMPRO Agent is required for continuous operation of the NEC Express5800/ft series. It is
automatically installed when installing OS using Express Setup.
To operate NEC ESMPRO Agent, you need to set the SNMP.
To change the settings of the SNMP Service:
1. Double-click [Administrative Tools] in [Control Panel].
2. Open [Services] in [Administrative Tools].
3. Select [SNMP Service] from the service list and then [Properties] in the [Action] menu.
The “SNMP Properties” dialog box appears.
4. Enter “public” in the [Community name] box in the [Traps] property sheet and click the
[Add to list] button.
IMPORTANT:
„ To change the community name of traps to be received from the default “*” in the
NEC ESMPRO Manager site, enter the same name as the community name newly
set in the NEC ESMPRO Manager site.
„ To receive trap from NEC ESMPRO Agent at the NEC ESMPRO Manager
machine, both community names should be the same.
5. Click the [Add...] button in [Trap destinations]. After entering the IP address of the NEC
ESMPRO Manager machine of the send destination in the [Host name, IP or IPX address]
box, click the [Add] button.
IMPORTANT: If the IP address (or host name) of the remote NEC ESMPRO
Manager specified as the trap send destination in the setup of the manager report
(TCP/IP), the message warning the duplication appears. The specification of the same
NEC ESMPRO Manager causes to be reported doubly.
