4-10 Windows Setup
3. Press the POWER switch which is located on the front side of the server.
IMPORTANT:
Do not turn off the power before the "NEC" logo appears.
Press the Power switch straight without your nail getting caught.
After a while, the "NEC" logo will appear on the screen.
While the "NEC" logo is displayed on the screen, NEC Express5800/ft series is performing
a power-on self test (POST) to check itself. For details, see the separate volume of User’s
Guide.
CHECK:
If the server finds errors during POST, it will interrupt POST and display the
error message. See the separate volume of User’s Guide.
CPU/IO module #1
Status LED
Module
power
switch
CPU/IO module #0
Status LED
POWER switch
FT Status LED
