10-30
Page 115
2008-10-01
C. SCHEDULE
2522478 FUSING NHTC/PC 100/550-600/3
2522479 FUSING NHTC/PC 150/208-240/3
2522480 FUSING NHTC/PC 150/440-600/3
2522481 FUSING NHTC/PC 200/208-240/3
2522482 FUSING NHTC/PC 200/440-480/3
2522483 FUSING NHTC/NHPC 200/550-600/3
Humidifier Information
Zone Label ___________ Zone Load ___________ Humidifier Output ______ External Protection _____
Humidifier Label _______ Humidifier Model _______ Voltage/Phase (VAC) ___ Requirement (A) _______
Control Information
Demand On/Off Transducer
By Nortec By Others By Nortec By Others By Nortec By Others
Space Control
High Limit
Air Proving By Nortec By Others None (Blower Pack)
Distributor Information
Blower Pack Built On
G
Remote Mounted
G
None (Duct)
G
Duct Information Width ___________ Length ___________
Vertical Airflow
G
Distributor ASD/BSD/CSD? _______
No. Of Distributors _____
Length ________ SAM-e
Header Length ________
Types of Tubs _________
No. of Tubes _________
Length ______________
