2. SUBMITTALS
A. INTRODUCTION
(1) The following pages are intended to be used by the engineer to determine the
component quantities required.
B. INSTALLATION COMPONENT SELECTION
(1) The following Tables 1 through 15 will enable the engineer to select components for
this installation.
Table 1. NH Series Unit Options
Part No. Description Qty
2522160 FILLCUP EXTENSION KIT NHTC/NHPC - 2 Required for 150 or 200
2522162 DRAIN WATER COOLER
005-020, to temper drain water below 120°F (49°C)
2522163 DRAIN WATER COOLER
030, to temper drain water below 120°F (49°C)
2522164 DRAIN WATER COOLER
050-075, to temper drain water below 120°F (49°C)
2522165 DRAIN WATER COOLER
100, to temper drain water below 120°F (49°C)
2522166 DRAIN WATER COOLER
150, to temper drain water below 120°F (49°C)
2522167 DRAIN WATER COOLER
200, to temper drain water below 120°F (49°C)
2522168 FOAM DETECTION NHTC HARDWARE
2522169 FOAM DETECTION NHPC HARDWARE
2522170 REMOTE FAULT INDICATION NHTC/NHPC
1469535 HIGH HUMIDITY ALARM PACKAGE
ON/OFF high limit duct stat w/indicator
1469536 LOW HUMIDITY ALARM PACKAGE
ON/OFF low limit duct stat w/indicator
1469537 HIGH HUMIDITY ALARM PACKAGE
ON/OFF high limit wall stat w/indicator
1469538 LOW HUMIDITY ALARM PACKAGE
ON/OFF low limit wall stat w/indicator
2522172 FACTORY PROVIDED EXTERNAL DRAIN AIR-GAP - REDUCER
146-9000 COUPLED CIRCUIT FOR DOUBLE UNIT
2522800 KEEPWARM, ALLOWING WATER TEMPERATURE IN THE CYLINDER TO
BE MAINTAINED AT 160°F (70°) FOR QUICK RESPONSE UPON A CALL
FOR HUMIDITY. NHTC OPTION ONLY.
2522803 UNIT NETWORKING NHTC AND NHTC OUTDOOR UP TO 1600 LBS/HR
ONE PACKAGE REQUIRED FOR EACH ADDITIONAL SLAVE HUMIDIFIER
DOUBLE UNIT 150/200 COUNTS AS 2 PACKAGES
