Appendix A
Specifications
A-2
ni.com
Clocks
Pixel clock frequency range....................20 to 50 MHz
Note
Camera Link cameras must transmit at a minimum of 20 MHz.
1
PCI Interface
Theoretical max PCI bandwidth .............133 MB/s
Memory
Onboard memory
PCI-1428..........................................16 MB SDRAM
PXI-1428 .........................................32 MB SDRAM
LUTs .......................................................Four 8-bit; two 10-bit to 16-bit
Serial Requirements
Baud rates supported ..............................300, 600, 1200, 1800, 2000, 2400,
3600, 4800, 7200, or 9600 bps;
19.2, 38.4, or 56 kbps
Power Requirements
Voltage
PCI-1428..........................................+5 V (1.5 A)
+12 V (24 mA)
–12 V (20 mA)
PXI-1428 .........................................+5 V (250 mA)
+3.3 V (1.2 A)
Physical
Dimensions
PCI-1428..........................................10.7 cm
× 17.5 cm
(4.2 in.
× 6.9 in.)
PXI-1428 .........................................10 cm
× 16 cm
(3.9 in.
× 6.3 in.)
1
This value corresponds to the post-serialization Camera Link cable transmission rate of 140 to 350 MHz.
