Appendix E Modifying and Installing I/O Expansion Boards
© National Instruments Corporation E-11 VXIpc 800 Series User Manual
Figure E-11. Front View of ISA Board Expansion Bracket
.490 [12.45]
(I/O Connector Window)
I/O Connector
Window, (490 [12.45] X
3.500 [88.90])
3.550
[90.17]
.09 [2.3]
(.200 [5.08])
4.46
[113.28]
4.080
[103.63]
.19 [4.8]
.180 [4.57]
.050 [1.27]
.560 [14.22]
.760 [19.30]
1
1 Install PEM self-clinching nut, P/N CLS-440-0, per
manufacturer's specifications, far side, or drill
through ø.125 [3.18] for 4-40 screw and nut.
