Appendix D Front Panel and Connectors
VXIpc 800 Series User Manual D-18 © National Instruments Corporation
13 –2 V +5 V –5.2 V
14 Not Connected D16 MODID06
15 Not Connected D17 MODID05
16 GND D18 GND
17 Not Connected D19 MODID04
18 Not Connected D20 MODID03
19 –5.2 V D21 -5.2 V
20 Not Connected D22 MODID02
21 Not Connected D23 MODID01
22 GND GND GND
23 TTLTRG1* D24 TTLTRG0*
24 TTLTRG3* D25 TTLTRG2*
25 GND D26 +5 V
26 TTLTRG5* D27 TTLTRG4*
27 TTLTRG7* D28 TTLTRG6*
28 GND D29 GND
29 Not Connected D30 Not Connected
30 GND D31 MODID00
31 Not Connected GND GND
32 Not Connected +5 V Not Connected
Table D-10. VXIbus P2 Connector Signals (Continued)
Pin Row C Row B Row A
