© National Instruments Corporation D-1 VXIpc 800 Series User Manual
Appendix
D
Front Panel and Connectors
This appendix describes the front panel and connectors on the
VXIpc 800 Series. This material contains the information relevant to
VXIplug&play Specification VPP-8, VXI Module/Mainframe to
Receiver Interconnection.
Note: The illustrations in this appendix show the mating face of the connectors.
An asterisk suffix (*) on a signal name indicates that the signal is active
low.
The VXIpc 800 Series has the following front panel connectors:
• Two RS-232 Serial
• Extended Capabilities Parallel (ECP)
• VGA Controller
• IEEE 488.2
• 10BaseT Ethernet
• SCSI-2
• External Clock
• Trigger Output
• Trigger Input
• Audio Output
• PS/2-Style Keyboard
• PS/2-Style Mouse
