Nokia M10 User’s Manual
DRAFT
E Copyright Nokia Telecommunications Oy NTC C33539002SE_A0 5-36
Command Show IP interfaces
Description Displays the IP interfaces of your M10.
Syntax show ip interfaces
Arguments None.
Example M10> show ip interfaces
IP Interfaces:
ENET (lan): (up broadcast default rip-
send v1 rip-receive v1)
inet 192.168.1.254
netmask ffffff00
broadcast 192.168.1.255
physical address 00.40.43.08.ff.ff
mtu 1500
PPP (vcc1): (up point-to-point rip-send
v2 rip-receive v2)
inet 10.98.20.21
netmask 0
peer address 10.98.20.1
physical address
00.00.00.00.00.00
mtu 1500
M10>
Command Show IP routes
Description Displays the IP routes stored in your M10.
Syntax show ip routes
Arguments None.
Example M10> show ip routes
IP gateway (route) table:
0. Default Gateway –> PPP (vcc1), D 2, T
0, (configured) UP DEFAULT
IP route cache
Net 192.168.1.1, gateway 192.168.1.1,
metric 0, timeout 0, via ENET (lan)
Net 192.168.1.255, broadcast, via ENET
(lan)
M10>
