Nokia M10 User’s Manual
DRAFT
E Copyright Nokia Telecommunications Oy NTC C33539002SE_A0 A-2
Hardware features
Data connector RJ-45
Local management interface
LMI connector RJ-45
Indicator lights
LAN LAN activity, status and collision
DSL ADSL line status
STA M10 status
A.2 Mechanical construction and power supply
The M10 ADSL router is a stand-alone device which can also be
wall-mounted using a wall-mount kit.
Mechanical construction
Width 294 mm
Height 56 mm
Depth 237 mm
Weight 2.5 kg
M10 has an in-built power supply. The characteristics of the mains
connection are presented in Table A-1.
Mains connection
Voltage 100 ... 240 VAC
Frequency 45 ... 65 Hz
Power consumption 9 W
Table A-1 Mains connection
A.3 Ambient conditions, EMC and safety
Installation environment
Unit’s operating temperature range 0 to 40
°
C
